CITO RSP System 2.0 - English

48
Operating Manual
Contents
Copyright © 2019 by
CITO-SYSTEM GmbH • Haimendorfer Str. 37+46 • 90571 Schwaig bei Nürnberg
Phone +49 911 95885-0 • Fax +49 911 95885-500 • info@cito.de • www.cito.de
Printed in Germany
List of abbreviations:
Fig. = Figure, P = Printing unit, C = Coating unit
EN
EN Operating Manual 47
Foreword 49
Basic safety instructions 49
1.DesignoftheRSPSystem2.0 50
2.MountingoftheRSPform/AssemblingtheRSPdirecttexibledie 52
3.InstallationinstructionsforRSPSystem2.0(generally) 54
1
st
Step: Mounting the RSP protective impression cylinder jacket 54
2
nd
Step:ClampingtheRSPbaseplate 56
3
rd
Step:FittingtheRSPgridsheetorRSPdirecttexibledie 57
4.InstallationinstructionsforRSPSystem2.0 60
4.1SM52PrintingUnitandSM52CoatingunitDryStarCoating
ClampingtheRSPbaseplate 60
4.2SM52Coatingunit 62
4.3CD74/XL75CoatingUnit 64
4.4XL105CoatingUnit 66
4.5Primere106–XL106AutoPlateCoating 68
4.6KBARapida105/106Coater 70
4.7manroland700PrintingUnit 72
4.8manroland500PrintingUnit 74
5.Therstpull–positioningcorrections 76
6.PositioningoftheRSPoffsetcreasingmatrices 78
7.Determiningthecylinderpackingthickness 80
8.Accessories 82
9.Recommendation 85
10.Troubleshooting 88
