Example:
Cylinder undercuts
blanket cylinder
Total thickness base
plate with mounted
RSP form
Total thickness base
plate with RSP direct
t exible dies
Total thickness
calibrated packing
sheets
2.30 mm 2.30 mm 2.00 mm no packing sheets
2.60 mm 2.30 mm 2.00 mm 0.30 and 0.20 mm
(manroland)
2.80 mm 2.30 mm 2.00 mm 0.50 mm
3.00 mm 2.30 mm 2.00 mm 0.70 mm
3.20 mm 2.30 mm 2.00 mm 0.90 mm
Maschine:
Importand note:
In some cases there is already foil glued to blanket cylinders the thickness of which must
be taken into account when determining the packing thickness!
Exception: No extra packings necessary with the XL 105 Coating Unit.
