CITO RSP System 2.0 - RSP Perforating Rules; RSP Cutting Rules

83
Operating Manual
321
3. RSP Perforating Rules (Fig. 1)
Description Cut : pitch Unit
4 tpi Perfo 6.0 : 0.7 mm 6 m
8 tpi Perfo 2.4 : 0.8 mm 6 m
12 tpi Perfo 1.4 : 0.8 mm 6 m
16 tpi Perfo 0.8 : 0.8 mm 6 m
18 tpi Perfo 0.7 : 0.7 mm 6 m
35 tpi Perfo 0.3 : 0.4 mm 6 m
50 tpi Perfo 0.2 : 0.3 mm 6 m
4. RSP Cutting Rules (Fig. 2)
Description Unit
Cut Rule 6 m
5. RSP Cutting Rules (Fig. 3)
Description Unit
Crease R1* 6 m
Crease R2** 6 m
* for creasing
** for creasing and cutting and/or perforating
