Citrix ByteMobile T1010 User Manual

T-Series Traffic Director Installation, Configuration and Administration Guide 1-19
Common Hardware Features
Power Supply
The T1000 ships with a dual power supply, configured for either AC or DC power. The AC
configuration includes two standard power cords that each have a NEMA 5-15 plug for
connecting to the power outlet on the rack or in the wall.
For power-supply specifications, see “T1000 Hardware Specifications and Options” on
page 1-6, which describes the various platforms and includes a table summarizing the
hardware specifications.
Note: If you suspect that a power-supply fan is not working, please see the description
of your platform. On some platforms, what appears to be the fan does not turn,
and the actual fan turns only when necessary.
For each power supply, a bi-color LED indicator shows the condition of the power supply.
Management
(RJ45)
Left Speed Off No
connection,
or a traffic
rate of 10
megabits per
second
(Mbps).
Green Traffic rate of
100 Mbps.
Amber Traffic rate of
1 gigabit per
second.
Right Link/
Activity
Off No link.
Solid yellow Link is
established
but no traffic
is passing
through the
port.
Blinking
yellow
Traffic is
passing
through the
port.
Port Type
LED
Location
LED
Function LED Color
LED
Indicates
