T-Series Traffic Director Installation, Configuration and Administration Guide 2-31
Accessing and Configuring the LOM Port
• Time zone
• Licenses
• Administrator password
Important: Before running the Setup Wizard, you should obtain your licenses from the
Bytemobile and put them in a location on your computer or another device
where you can access them from your Web browser during configuration.
Note: If the T1000 is configured with the default IP address, licenses are not installed
on the T1000, or the mapped or subnet IP address is not configured, the
configuration utility automatically opens the Setup Wizard when you log on to
the T1000.
To configure initial settings by using the Setup Wizard:
Step 1 In a Web browser, type: http://192.168.100.1
Note: The operating system is preconfigured with a default IP address and associated
netmask. The default IP address is 192.168.100.1 and the default netmask is
255.255.0.0.
Step 2 In User Name and Password, type the administrator credentials.
Note: The T1000 default username is nsroot and the default password is nsroot.
Change these values as soon as possible.
Step 3 In Start in, select Configuration, and then click Login.
Step 4 In the Setup Wizard, click Next, and then follow the instructions in the wizard.
Note: To prevent an attacker from breaching your ability to send packets to the T1000,
choose a non-routable IP address on your organization's LAN as your T1000 IP
address.
Step 5 You have now completed initial configuration of your T1000.
Accessing and Configuring the LOM Port
The T1000 has an Intelligent Platform Management Interface (IPMI) also known as the
Lights out Management (LOM) port on the front panel. Using LOM, you can remotely
monitor and manage the T1000 independently of the operating system. You can remotely
change the IP address, power cycle the T1000, and perform a code dump by connecting to
the T1000 through the LOM port.
