ENGINE
199
CHECKING AND SETTING THE VALVE TIMING
Engines : RHY - RHZ N° RPO 9128 #
Tools.
[1] Belt tension measuring equipment : 4122-T
[2] Tension lever : (-).0188.J2.
[3] Engine flywheel peg : (-).0188.Y.
[4] Belt clamp : (-).0188.AD
[5] Camshaft pulley peg : (-).0188.M
[6] Engine flywheel lock : (-).0188.F.
[7] Set of blocking plugs : (-).0188.T.
[8] Pulley extractor : (-).0188.P.
[9] 2 mm dia.peg : (-).0188.Q2
Removing
IMPERATIVE : Respect the safety and cleanliness requirements
that are specific to high pressure diesel injection (HDi) engines.
Undo the front RH wheel bolts.
Raise and support the vehicle on the front RH side.
Disconnect the battery negative terminal.
Remove :
The under-engine sound-deadening.
The front RH wheel.
The front RH splash-shield.
The engine cover.
Unclip and move aside the cooling hose.
Remove the accessories drive belt.
(See corresponding operation).
XSARA - XSARA PICASSO
