202
ENGINES
CHECKING AND SETTING THE VALVE TIMING
Engine: RHR
Tools.
[1] Kit of plugs : (-).0188.T
[2] Double flywheel setting peg : (-).0188.X
[3] Camshaft setting peg : (-).0188.M
[4] Belt clamp : (-).0188.AD
[5] Pinion centrer : (-).0188.AH
[6] Flywheel lock : (-).0188.F
[7] Pulley : (-).0188.P
IMPERATIVE: Respect the safety and cleanliness requirements specific to High pressure Diesel injection (HDi) engine versions.
Removing.
Slacken the front RH wheel bolts.
Raise and support the front RH side of the vehicle.
Disconnect the negative terminal of the battery.
Remove:
- The under-engine sound-deadening
- The front RH wheel
- The front RH splash-shield.
- The engine cover.
Remove the auxiliaries drive belt (see corresponding operation).
