Clemens Technologies RADIUS SL PLUS User Manual

RADIUS SL PLUS 03.2019 en 75
Item no.
Specification
Remark
Quantity
Order no.
Override valve electric 1-sided
complete items 2 - 13
CG856.097000
1
Mounting bar standard
complete items 1.1 – 1.5
1
CB856.085000
1.1
Fastening section
1
CA856.085100
1.2
Support section
1
CB856.085200
1.3
Hexagon head screw
1
093312020
1.4
Hexagon head screw
2
093106090
1.5
Hexagon nut
2
098506
2
Flow divider / Return oil manifold
for details see 10.28
1
CA895.381000
3
Valve housing
incl. expander
2
CA895.391101
4
Pressure relief valve with valve housing
complete items 4.1 – 4.2
1
CA895.391200
4.1
Valve housing
1
CA895.391201
4.2
Pressure relief valve
1
CW760.011600
5
Electric parts complete 2 sided
complete incl. items 5.1 – 5.8
CK895.391300
5.1
Magnetic clamp
with hook
1
CW500.010200
5.2
Housing
1
CK895.391310
5.3
Toggle switch
2
CW820.027900
5.4
Signal light LED
2
CW820.028000
5.5
Cable
1
CW830.000100
5.6
Cable fitting
3
CW830.033900
5.7
Plug 3-pin
1
CW830.044200
5.8
Valve connector
incl. cable 4000 mm (157.5”)
2
CW830.099900
6
Coupling plug
1
CW720.000200
7
Coupling plug
1
CW720.001000
8
Dust cover
1
CW720.005900
9
Dust cover
1
CW720.006000
10
Straight screw socket
2
CW730.008600
11
Straight screw socket
7
CW730.008800
12
Screw-in fitting
6
CW730.031700
13
Electrovalve 4/2 ways
2
CW760.010900
14
Cable tie black
not shown
14
CW830.063300
Note:
When ordering hydraulic hoses for replacement, measure the length "L" (including pressed
fittings) and indicate in mm (Conversion aid: 1” = 25.4 mm).
Note:
When ordering the hydraulic hoses B and C, pay attention to the different lengths to the right
and left basic unit.
Note:
Item no. 1 Mounting bar for flow divider may differ depending on the mounting frame used:
For HEXAGON frames we use the Mounting bar CC856.085000
For TERACTIV frames, an additional CL860.010009 clamping strap and two screw-on sets
093112110 + 098512 + 012315 are required. The order number of the complete group item no.
1 + additional parts is CE856.085000.
For SB frames, the fastening section pos. 1.1 is welded to the frame.
