Advanced M52 Microprocessor User's Guide
ADVANCED M52UMCT2019 COLOR
44
ddress Jumpers
LED Power
1,2, 3, 4 bit code represents the RS485 address, when the shifting to the ON position are respectively corresponding to
8,4, 2, 1 values; All in the numerical Off position corresponding to 0.
RS485
4
3
2 1
1 0 0 0 0
2
0
0
0
1
3
0
0
1
0
4
0
0
1
1
5
0
1
0
0
6
0
1
0
1
7
0
1
1
0
8
0
1
1
1
9
1
0
0
0
10 1 0 0 1
11 1 0 1 0
12 1 0 1 1
13 1 1 0 0
14 1 1 0 1
15 1 1 1 0
16 1 1 1 1
Now we only use RS485 Address 11&12
RS485 Address 11 is the return Air Sensor.
RS485 Address 12 is the supply Air Sensor.
Other Address can use in Sensor Hub
