HCS User Manual
18
MOUNTING PROCEDURES
Locate the wall mounting position of the EVSE:
• On the hardwired HCS, the three service conductors are
unit. The HCS must be positioned such that this conduit can
reach a nearby junction box.
• On the plug-in HCS, the NEMA plug head is connected by one
foot of cable (including the plug head) to the bottom side of the
HCS. The plug-in HCS must be positioned such that this plug
can safely be inserted into a wall-mounted NEMA socket.
• Position the bottom of the EVSE at a comfortable height and
at least 18 inches above the ground for indoor installations and
24” off the ground for outdoor installations. Ensure that the
LEDs on the front panel of the EVSE can clearly be seen by
the user of the device.
• The HCS has two vertically aligned mounting holes spaced 17”
apart, one each on the enclosure top and bottom. Use a ruler or
template to mark hole locations on the mounting surface.
WARNING: For safety, always turn off input power to the
EVSE at the circuit breaker panel prior to plugging it in or
wiring it to the service lines. Likewise, turn off the circuit
breaker prior to unplugging it or disconnecting the unit
from the service lines.
AVERTISSEMENT: Pour sécurité, toujours désactiver
le courant d’entrée de la station de recharge au niveau du
disjoncteur du panneau avant de le brancher ou de câblage
à les lignes de service. De même, coupez le disjoncteur
avant de le débrancher ou déconnecter l’unité à partir des
lignes de services.
