HCS User Manual
49
SPECIFICATIONS
Line Input Power 240V AC single-phase - L1, L2, and Safety Ground.
Voltage & Wiring: 208V AC 3-phase wye-connected - Any two phases and
Safety Ground.
240V AC 3-phase, delta-connected. With center-tap on
one leg, must use only the two phases on either side of
the center-tap. The two phases must both measure 120V
AC to ground. Do not use the third leg (208V “Stinger”).
Supplied Input Pre-installed supplied input conductors of the HCS-15, 20,
Conductors: 25, 30 or 40: L1, L2 and Ground use 3 feet of 10AWG, 90ºC
copper wire.
Pre-installed supplied input conductors of the HCS-50, HCS-60,
and HCS-80: L1, L2 and Ground use 3 feet of 8AWG, 90ºC
copper wire.
Voltage Range: 185V AC to 264V AC
Frequency: 60 Hz
CCID: 20mA
Current & Output HCS Model Circuit Max Output Cable
Power: (at 240V AC) Number Breaker Current Power Length
HCS-15 (hardwired) 15A 12A 2.9 kW 25 ft (7.6m)
HCS-20 (hardwired) 20A 16A 3.8 kW 25 ft (7.6m)
HCS-20R (hardwired) 20A 16A 3.8 kW 25 ft (7.6m)
HCS-25 (hardwired) 25A 20A 4.8 kW 25 ft (7.6m)
HCS-30 (hardwired) 30A 24A 5.8 kW 25 ft (7.6m)
HCS-30R (hardwired) 30A 24A 5.8 kW 25 ft (7.6m)
HCS-40 (hardwired) 40A 32A 7.7 kW 25 ft (7.6m)
HCS-40P + 6-50P 40A/50A 32A 7.7 kW 25 ft (7.6m)
HCS-40P + 14-50P 40A/50A 32A 7.7 kW 25 ft (7.6m)
HCS-40R (hardwired) 40A 32A 7.7kW 25 ft (7.6m)
HCS-40PR + 6-50P 40A/50A 32A 7.7 kW 25 ft (7.6m)
HCS-40PR + 14-50P 40A/50A 32A 7.7 kW 25 ft (7.6m)
HCS-50 (hardwired) 50A 40A 9.6 kW 25 ft (7.6m)
HCS-50P + 6-50P 50A 40A 9.6 kW 25 ft (7.6m)
HCS-50P+14-50P 50A 40A 9.6 kW 25 ft (7.6m)
HCS-60 (hardwired) 60A 48A 11.5 kW 25 ft (7.6m)
HCS-60R (hardwired) 60A 48A 11.5 kW 25 ft (7.6m)
HCS-80 (hardwired) 80A 64A 15.4 kW 25 ft (7.6m)
HCS-80R (hardwired) 80A 64A 15.4 kW 25 ft (7.6m)
NOTE: The maximum current for the vehicle is set by the duty cycle of
the Pilot waveform. Output power is variable depending upon
the HCS model and vehicle demand.
Plugs: An attached NEMA 6-50P or NEMA 14-50P plug is
available on the HCS-40P and HCS-50P.
Dimensions: Dimensions are for the enclosure only:
Height: 500 mm (19.7 inches)
Width: 225 mm ( 8.9 inches)
Depth: 135 mm ( 5.3 inches)
