Index
0Introduction Errore. Il segnalibro non è
definito.
0.1 Content of the manual 1
0.2 Disclaimer  2
0.3 Where and how to keep the
manual 3
0.4 Regulatory references 4
0.5 Amendments and integrations 5
1Specifications 9
1.1 Technical sheet  9
1.2 Identification plate 8
1.3 CE certification Errore. Il
segnalibro non è definito.
1.4 TÜV certification Errore. Il
segnalibro non è definito.
1.5 Classification  Errore. Il
segnalibro non è definito.
1.6 Loading cycles  Errore. Il
segnalibro non è definito.
1.7 Working diagram and stabilization
areas 13
2Description and purpose 6
2.1 Definition 6
2.2 Machine purpose 6
2.3 Description of the MEWP
components  14
3Control positions 16
3.1 Engines ignition station 16
3.2 Platform control stations 22
3.3 Emergency control stations 29
4Use procedures 33
4.1 General safety rules 33
4.2 Environmental operating
conditions 33
4.3 Transport, storage and packaging
35
4.4 MEWP use procedures 40
4.5 Lithium battery pack recharge
(*optional) 48
4.6 Emergency manoeuvres 49
4.7 Work safety rules  58
4.8 Safety devices  64
4.9 Residual risks 66
5Markings 68
6Electrical system 80
7Hydraulic system 82
8Maintenance 83
8.1 Daily maintenance  84
