Adjustable Operating Parameters and Options
BodyGuard 323
The BodyGuard 323 pump has adjustable operating parameters. These operating
parameters and options may be viewed and adjusted to modify the operation of the
pump. The operating parameters and options available for the BodyGuard 323 are
described below in the Techncian Menu, Change Set Up Menu, Program Lock, and
Keypad Lock sections. If access to a specific mode of operation is required (i.e.
Continuous, Intermitent, PCA, TPN, or 25 steps), refer to the operation manual for
instructions.
Technician Menu
To
access the Technician Menu, press and hold the INFO key during the power on
operation until ‘Technician Code’ prompt appears. The display will show the software
version for 2 seconds before the access code prompt. Enter Technician Code to access
the Technical Menu.
The pump will display all the parameters that can be set, calibrated or tested. The
technician can scroll through all parameters using the ARROW keys (2 & 0 keys on
the pump).
Item
Parameter Description
1
Restart Pump Exit Technician Mode.
2
Serial Number Displays serial number & production date.
3
Manual Calibration Summary of volume & pressure calibrations and ability to check/re-
enter software default calibrations after service.
4
Main Self-Test Performs keypad, display, alarm sound, door sensor, air sensor,
temperature, motor & encoder, and pressure sensor tests.
5
Manual Test Same as Main Self-Test but with a menu so technician can focus on
individual tests.
6
Pressure Calibration Allows manual calibration of pressure settings.
7 Volume Calibration Allows manual calibration of pumping mechanism.
8
Software default
Setting
Caution: pressing START/OK will restore software defaults and
delete all pre-set protocols and set-up changes.
9
Reset Calibrations Caution: pressing START/OK restores default settings. Pump must
be re-calibrated after reseting calibrations.
10
Operating time/
hours counter
Hours from last service – reset to zero by pressing STOP/NO key.
