Tools and Test Equipment
The following tools and test equipment are required to perform the procedures
contained in this manual. Since all fasteners on this device are metric, ensure that
all tools used are for metric fasteners.
Test Equipment
• Digital voltmeter (Fluke 115 or equivalent)
• BodyGuard Operations Manual
• PC with a RS232 9way Serial port
• BodyComm Communication Software*
• BodyComm Operations Manual*
• BodyComm Communications Charger (150-318X)*
• BodyGuard Charger may be required (pulse oximeter charger for 545,
and 575)
• RS 232 cable (197-000X)**
• ESD work station Mat and Wrist Strap
• BodyGuard tubing set with proximal Y-Site**
• Infusion Bag (sterile water for injection)
• Scale (.01g resolution)
• Pressure Gauge, maximum pressure 30psi, .01 psi resolution
• Timer (seconds resolution)
• Burning Station PN 100-405X* (for software updates)
• 5 pin male to male connection wire*
• Prog08sz software*
Tools
• Phillips screwdriver, M3
• Flat screwdriver, M3
• Allen key 2.5 mm
• Forceps
• 2mm Push shaft
• Air Sensor ‘Go No-Go’ gauge/or gauge pins (GO, 2.2 mm, No-GO, 2.3 mm)
• Sharp knife
• 3 ml Syringe with graduated markings
• DC Cable BG (196-000X)*
