Procedure:
1. Fill the IV bag with room temperature sterile water. It is important that the
water be room temperature so that it does not affect the elastic properties of
the silicone replacement pumping segment. Once the IV bag has been filled,
use a BodyGuard tube set to spike the IV bag. Hang the IV bag and the tube
set from the IV pole. To prevent fluid coming into contact with the air
sensor and pumping mechanism, the infusion bag should be spiked before
opening the pump door. Position the bag so that the risk of spillage onto/into
the device is minimized. Do not stretch the set when removing it from its
packaging or installing it in the pump.
2. Attach the BodyGuard pole mount charger so that the pumping chamber is
10” below the IV bag on the IV pole. This will ensure that the pumping
segment will reach the pumping chamber once the pump has been inserted
into the pole mount charger. Load the pump into the pole mount charger and
insert the pumping segment of the tube set into the pumping chamber.
3. Power on the pump and set the BodyGuard 323 parameters in the following
table using steps below:
a. Press the INFO button until the option “Change Setup” appears. Press
the Start/OK button.
b. Using the down arrow (zero button scroll to the option) “More” and press
the Start/OK button.
c. Enter Change Set Up Code and press the Start/OK button.
d. Scroll through the menu and adjust the values so that they match the
table above.
e. Once all values have been confirmed, select the option “Restart Pump”.
4. To calibrate volume for the BodyGuard 545 and 575, use the “Volume Test”
found in the technician menu and disregard step 3.
Scroll through the menu and adjust the values so that
they match the table below. Setting
Required Value
Pressure Default 14 PSI
Pump Program Continuous
Maximal Rate 1200 ml/hr
KVO Rate 0.0 ml/hr
Set Loading Test Off
Time Option Off
