6.2.1. WAN Connection Named Rule
The WAN Connection has the following rule for the Network Name parameter:
<Numerical order>_<Keywords>_<Bridge_or_Router>_<VLAN>
The following table explains the parameters to build the Network Name:
Content
Definition
Description
Numerical order
Sequence number
It is a number to identify the WAN
Connection, following the next rule: number
in increasing sequence based on the
sequence of the WAN connections created.
No reuse of the number already used.
Keywords
TR069
The connection is used for TR069 (Technical
Report 069, CPE WAN Management Protocol
(CWMP)).
INTERNET
The connection is used for INTERNET. There is
no support for the TR069.
TR069_INTERNET
The connection is used for INTERNET and the
TR069.
Bridge or Router
B
Bridge Mode
R
Router Mode
VLAN
VID_Z
Z of VID_Z is the VLAN_ID value (for untag
WAN Connection, value of Z is Null and do
not appear in the connection name）
Table 4
For
example:
• 1_INTERNET_R_VID_2: this WAN Connection is used for INTERNET, working mode is
Router and VLAN ID is 2.
• 2_INTERNET_B_VID_: this WAN Connection is used for INTERNET, working mode is
Bridge, VLAN ID is Null.
NOTE
: TR-069 (CPE WAN Management Protocol – CWMP) is a bidirectional SOAP/HTTP-
based protocol which provides the communication between customer-premises
equipment (CPE) and Auto Configuration Servers (ACS). It includes both a safe auto
configuration and the control of other CPE management functions within an integrated
framework. The protocol addresses the growing number of different Internet access devices
such as modems, routers, gateways, as well as end-user devices which connect to the
Internet, such as set-top boxes, and VoIP-phones. The TR-069 standard was developed for
automatic configuration and management of these devices by Auto Configuration Servers
(ACS).
