Setup using the web interface
98-144390-A Chapter 4: Setup and operation 4-9
4.1.5 Navigation
On this page you can enter a fixed position or a fixed base heading. Do as follows:
1. Select SERVICE > Navigation from the left navigation pane.
2. Set the Position:
3. Click Apply to save the new settings.
4.1.6 Administration
In this section of the web interface you can configure the following administrative settings:
• Access to the administration settings (user name, password)
• User permissions (guest login)
• Import and export of a system configuration
• Reset to factory default
Access to the administration settings (user name, password)
You can logon as an administrator or as guest (user name: guest, password: guest). The
Administration settings require an Administration user name and password. To log on as
administrator, do as follows:
1. Enter the IP address of the EXPLORER 3075GX.
2. Enter the Administration user name and password.
Figure 4-7: Web interface: SERVICE > Navigation
Item Description
Position mode GPS - GNSS module is used for current position (default).
Manual - enter values from other position source. (Accuracy should
be better than 50 m.)
Table 4-4: Web interface: SERVICE > Navigation
