A.2 Product Dimensions
The dimensions shown below reflect the space needed to accommodate the full range of
motion in elevation and azimuth.
A.2.1 Side view
Figure A-1: EXPLORER 3075GX side view
40” / 102 cm
30” / 76 cm
