Setup using the web interface
4-6 Chapter 4: Setup and operation 98-144390-A
4.1.3 To configure the LAN network
On this page you can set up the LAN network and enter a host name. The host name helps
identifying the EXPLORER 3075GX system. The EXPLORER 3075GX has four 10/100 Mbit
ports labelled LAN 1, 2, 3 and 4. LAN1 is the service port. LAN2, LAN3 and LAN4 are
controlled by the GX modem.
To configure the LAN network, do as follows:
1. Select SETTINGS > Network.
2. Make the necessary changes on this page and click Apply.
The EXPLORER 3075GX system is not designed to be connected directly to
the Internet. It must be located behind a dedicated network security device
such as a firewall. If any ports of the EXPLORER 3075GX are exposed to the
Internet you must change the default passwords as anyone with access and
malicious intent can render the EXPLORER 3075GX inoperable.
Figure 4-5: Web interface: SETTINGS, Network (default settings)
Make sure that the networks do not use IP address ranges that overlap.
