Setup using the web interface
98-144390-A Chapter 4: Setup and operation 4-5
Information fields on the Dashboard
DASHBOARD Description
System status Current status of the EXPLORER 3075GX
.
Examples:
Antenna software upload
Antenna POST (Power-On Self Test)
Ready (waiting for data from the modem or no satellite profile
selected)
Deployed idle (antenna ready)
Manual pointing
Acquisition ok (signal from the GX satellite acquired)
Safe mode (error, followed by an error description)
GPS position Current position, reported by the GNSS module
Base orientation Orientation of the electronics enclosure.
Not used by this antenna.
Satellite profile Name of the currently active satellite profile.
Satellite position Position of the satellite selected in Satellite profile.
Azimuth Current value for azimuth.
Elevation Current value for elevation.
RX RF frequency Ka band receiving frequency, auto-selected by modem
Tuner signal strength Current tuner signal strength
Tuner mode GSC (GX) or Narrowband
Tracking RF frequency Current RF tracking frequency
Antenna TX allowed Not allowed or Allowed
Modem RX status Not locked or Locked
ACU part name, Antenna
part name, ACU serial
number, Antenna serial
number, Software
version
Part names, serial numbers for antenna, software version of the
EXPLORER 3075GX.
Table 4-2: Web interface: DASHBOARD
