MBF-40 SMR700/SMR800 PS REPEATER
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless Date: 28-Jan-16 Cobham Wireless – Coverage
Page | 28
Rev. 2.1 Doc. No. 00046UM
To connect the power cables
1. Refer to the power requirements as described in section 2.2.3.
2. Open the repeater door.
3. According to the repeater model, route the
power cable through the power interface
and towards the power plinth.
Figure
2-24: Example of MBF-40 Model
4. -48VDC, connect wires to the plinth as
follows:
• Phase linked to brown cable
• Neutral linked to the blue
• Ground to the yellow/green.
Figure
