98-175666-D Chapter 3: Setup of the antenna 3-25
The following parameters are recorded in the statistics report:
Parameter recorded Description
Host name Host name, entered in the web interface
on the page Settings > Network.
BDU SN BDU serial number
ADU SN ADU serial number
SW ver. Software version
System type SAILOR 1000 XTR GX-R2 4.5W (example)
Table 3-15: Statistics report, header record
Parameter recorded Description
UTC. (s)
UTC (YYYY-MM-DD hh:mm)
UTC in seconds and date format for the data set.
RSSI.Av
RSSI.Max
RSSI.Min
Received signal strength (average, maximum and
minimum value) for the sampling interval.
POS.Lat (degree)
POS.Long (degree)
POS.Valid
Latitude value of position.
Longitude value of position.
Fix = valid position, No Fix = invalid position.
Heading.Samp (degree)
Heading.Max (degree)
Heading.Min (degree)
Heading.Range (+/-degree)
Ship’s heading (sample, maximum and minimum
value, range) for the sampling interval. See Figure
3-18: Statistics — how to read data for a range.
Antenna.Azi (degree) Antenna.Azi
Max (degree) Antenna.Azi Min
(degree) Antenna.Azi Range (+/-
degree)
Current antenna azimuth (sample, maximum and
minimum value, range) for the sampling interval.
See Figure 3-18: Statistics — how to read data for
a range.
Antenna.Ele (+/-degree)
Antenna.Ele Max (+/-degree)
Antenna.Ele Min (+/-degree)
Current antenna elevation (sample, maximum
and minimum value) for the sampling interval.
Vsat.rx_lo_freq (GHz)
Vsat.tx_lo_freq (GHz)
Rx frequency of VSAT modem for this record.
Tx frequency of VSAT modem for this record.
Tracking.rf freq (GHz)
Tracking.type
Tracking RF frequency for this record.
Narrow filter, DVB-S2 decoder.
Sat.long (degree) Longitude position of the satellite.
Carrier rf.rx (GHz)
Carrier rf.tx (GHz)
Rx frequency of carrier for this record.
Tx frequency of carrier for this record.
Table 3-16: Parameters in a statistics report
