IP5000 1.0 Series
Administrator Guide
3.1 Connectors, Ports and Switch List
TheIP5000speakerphonecomeswithyourchoiceofsinglebutton,dualbuttonordual
buttonwithkeypadfaceplate.Theinternalcomponentsconsistofaspeaker,microphone,
PCBandmountinghardware.
IP5000 speakerphone
OPTIONAL BATTERY
12V @ 2.0 Ahr
AUX
PORTS
LAN PoE LAN 1 LAN 2 PAS
CONTROL
PAS
AUDIO
AUDIO
OUTPUT
Power Connector
BatteryConnector
PoE LAN Port
LAN Ports
AuxiliaryInput/OutputConnector
PAS Control Connector
Line Level Audio Output Connector
Button Connectors
Microphone/LEDConnector
Speaker Connector
Reset Switch
KeypadConnector
