DataMan 150 or DataMan 260 Readers with a 16 mm Lens
The following tables show the field of view (FoV) widths of the 16 mm lens at various distances.
DM150 or DM260
Distances in mm 2D min. code 1D min. code
80 3 MIL 2 MIL
150 5 MIL 3 MIL
190 6 MIL 4 MIL
225 7 MIL 4 MIL
375 12 MIL 5 MIL
500 15 MIL 10 MIL
1 m 25 MIL 15MIL
DM152 or DM262
Distances in mm 2D min. code 1D min. code
80 2 MIL 2 MIL
150 3 MIL 2 MIL
190 4 MIL 2 MIL
225 4 MIL 3 MIL
375 7 MIL 4 MIL
500 10 MIL 6 MIL
1 m 20 MIL 15MIL
The following maps show the FoV of the DataMan 150/260 and DataMan 152/262 readers with a 16 mm lens. The
horizontal and vertical field of view is shown for working distances of 80 mm, 150 mm, 225 mm, 375 mm, 500 mm and
1000 mm.
