The following table lists typical values for this application:
Parameter Typical Values
Line speed 50 FPM
Nominal working distance 6-12"
Working distance range +/- 5"
Working width 6"
Tilt, pitch, and rotation +/- 2°
Code module size 20 Mil
Codes per minute 20-30
Trigger and output signals Optional
Side Scanning
Side scanning applications typically involve reading a single barcode at a consistent distance but a variable offset.
The following table lists typical values for this application:
168
Application Guide
