Cognex DataMan 70 - Dataman 360 Series Reader Dimensions

DataMan 360 Series Reader Dimensions
DataMan 360 dimensions without lens and with C-mount and S-mount lens options:
1 M3-5 (4x) mounting holes of the device
2 M3-6 (4x) mounting holes for external illumination
3 Illumination lights
4 Operating buttons
A C-Mount Lens version
B S-Mount (M12)Lens version
19
Mechanical Information
