Note: The flat side of the gasket (marked as "Front" in the image above) has to face outside.
WARNING: Do not touch any electrical component.
3. Reattach the I/O connector module to the main module.
DataMan 150 DataMan 260
4. Reinstall the washers and loosely fasten the modules together with the two T10 cap nuts, but do not tighten.
DataMan 150 DataMan 260
78
Mechanical Information
