DAILY MAINTENANCE
PERFORM ALL MAINTENANCE OPERATIONS IN SEQUENCE
1. CLEANING THE RECOVERY TANK
1. Take the machine in an area designated for the disposal of liquids
ATTENTION: Before performing any maintenance, remove the keys from the
panel and disconnect the battery connector of the machine.
WARNING: this operation must be carried out wearing gloves to protect
against contact with dangerous solutions.
2. Engage the parking brake.
3. Lift the brush head and squeegee from the ground.
4. Raise the cap (2) until the hook is secured to the prop (3) of the recovery tank.
5. Clean and rinse the recovery tank and the suction pipe (connecting pipe between the squeegee
and the tank).
6. Reposition the cap on the drainage tube and lower the suction cap. To lock the prop (3) just slightly
raise the cap, release the prop (3) and lower the cap up to close it.
2. CLEANING THE SUCTION FILTER
1. Engage the parking brake.
2. Lift the brush head body and the squeegee body off the ground.
3. Raise the cap (2) until the hook is secured to the prop (3) of the recovery tank.
4. Remove the suction filter protection (1) by rotating it clockwise.
5. Remove the suction filter (4) from its seat.
6. Use a jet of water to clean the walls and brush head of the filter.
7. Reassemble all the elements.
WARNING: Before carrying out any type of maintenance, disconnect the
machine's power supply cable.
ATTENTION: These operations must be carried out using gloves to protect
against contact with dangerous solutions.
3. CLEANING THE SUCTION TUBE FILTER
1. Raise the suction cover and block it as indicated in the previous paragraph.
2. Check that the parking brake is engaged.
3. Rotate the inner filter (1) and remove it.
4. Carry out the cleaning operations carefully.
5. Reassemble all the elements.
WARNING: Before carrying out any type of maintenance, disconnect the
machine's power supply cable.
ATTENTION: These operations must be carried out using gloves to protect
against contact with dangerous solutions.
2
3
4
1
1
