WEEKLY MAINTENANCE
1. CLEANING THE SQUEEGEE TUBE
Every week, or whenever suction seems to be unsatisfactory, check the squeegee tube is not obstructed.
To clean it, proceed as follows:
1. remove the tube from the sleeve on the squeegee.
2. Release the hinges on the upper part of the machine.
3. Open the recovery tank.
4. Remove the other end of the tube (2) from the hose connector (1) of the recovery tank.
5. Wash the inside of the tube with running water to remove any impurities that prevent proper suction
6. Reassemble all the elements.
WARNING: Before carrying out any type of maintenance, disconnect the
machine's power supply cable.
2. CHECKING THE WHEEL BRAKE
Every week, check the distance between the work brake pads and the wheels. If necessary, adjust them
by means of the nuts, so they are at a distance of 3mm when homed.
WARNING: Before carrying out any type of maintenance, disconnect the
machine's power supply cable.
3. CLEANING THE SOLUTION TANK
1. Engage the parking brake.
2. Loosen the front cap of the solution tank.
3. Remove the clean water filter.
4. Unscrew the filter cap at the rear of the machine.
5. Rinse the inside of the tank with a jet of water
6. Insert the cap and the filter at the front of the tank and screw the cap on the rear of the machine.
WARNING: Before carrying out any type of maintenance, disconnect the
machine's power supply cable.
ATTENTION: These operations must be carried out using gloves to protect
against contact with dangerous solutions.
4. REPLACING THE SQUEEGEE RUBBERS
Vacuum will be poor and the machine will not dry perfectly if the front squeegee rubber is worn. Proceed
as follows to replace it:
1. Raise the squeegee body by turning the lever anticlockwise.
2. Check that the parking brake is engaged.
3. Remove the suction tube from the squeegee.
4. Turn the handwheel counterclockwise (1) and remove the pin (2) from its housing in the squeegee
coupling.
5. Remove the pin (3) from its housing in the squeegee coupling.
