SYMBOLS USED ON THE MACHINE

Tap symbol

Used to indicate water regulation changes (CDS versions)

Detergent symbol

Used to indicate detergent regulation changes (CDS versions)

Indicator showing battery charge level on the upper line and hour meter on the lower line (B-BT versions)

Indicator showing the type of hour meter (total) on the upper line and the type of service (none) on the lower line

Indicator showing the type of technology of the batteries used (lead) (B-BT versions)

Battery symbol (B-BT versions)

Warning high voltage 110-220 Volt

Indicates the maximum temperature of the detergent solution

Located near the solution tank inlet

Indicates the risk of crushed hands

Indicates the instructions for dosing the detergent in the canister (CDS version)

Indicates the earth connection point of the electric system of the machine. (E versions)

Indicates the maximum gradient
