DAILY MAINTENANCE
6. DISASSEMBLING THE BRUSH (DUAL BRUSH HEAD)
1. Turn the key of the master switch to the anticlockwise to the "0" position, and remove the key, for the
electric versions disconnect the plug from the mains socket.
2. Check that the parking brake is engaged.
3. raise the brush head, using the lever
4. With the base up, rotate the brush until it comes out of the brush-holder plate seat, as shown in the
figure. The drawing shows the rotation direction to uncouple the brush of duel-brush heads, the
rotation direction for single-brush heads is anticlockwise.
5. Always check the bristles for signs of wear. You are advised to replace the brushes when the bristles
are less than 15 mm long.
WARNING: Before carrying out any type of maintenance, disconnect the
machine's power supply cable.
ATTENTION: this operation must be carried out using gloves to protect against
contact with dangerous solutions.
