ComAp ECON-4 Reference Guide

ECON-4, SW version 1.4 rev.1, ©ComAp – March 2016 Draft 16
ECON-4 Reference guide.pdf
P13 Test purposes only
P14 HW signalization of ACT overload, MUST be ON
P20 Test purposes only
P21
Feedback circuit supply.
10V – link 2 pins from the left side – use for Heinzmann actuators
5V – link 2 pins from the right side – use for GAC, Woodward actuators
P22
AIN 1 switch between current and voltage
Current: link the 2 pins from the left side
Voltage: link the 2 pins from the right side
P23
AIN 2 switch between current and voltage
Current: link the 2 pins from the left side
Voltage: link the 2 pins from the right side
