ComAp ECON-4 Reference Guide

ECON-4, SW version 1.4 rev.1, ©ComAp – March 2016 Draft 55
ECON-4 Reference guide.pdf
Technical data
Power supply
Voltage supply 8-36V DC
Consumption 0,5 - 8A depend on supply voltage and actuators
Operating conditions
Operating temperature -30..+70
o
C
Storage temperature -30..+80
o
C
Protection IP00
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 50081-1:94, EN 50081-2:96
EN 50082-1:99, EN 50082-2:97
Vibration 5 - 25 Hz, ±1,6mm
25 - 100 Hz, a = 4 g
Shocks a = 200 m/s
2
Dimensions and weight
Dimensions 155x151x57mm
Weight 600g
Binary inputs and outputs
Binary inputs
Number of inputs 8
Input resistance 4,4kΩ
Input range 0-36VDC
Switching voltage level for close contact indication 0-2V
Max voltage level for open contact indication 8-36V
Analog inputs
Not electrically separated
Resolution 10 bits
Range 0 – 10V; Input resistance 11kΩ
0 – 20mA; Load resistor 50Ω
Analog measurement tolerance 1 %
Analog outputs
Not electrically separated
Resolution 0 – 10000
Range 0 – 10V; Output resistance < 1Ω
0 – 20mA; Active current source
Actuator feedback input
Not electrically separated
Resolution 10 bits
