RPM window [RPM]
In case the actual RPM differs from Requested RPM for more than RPM window [RPM], the Speed
PID constants fluently change from Speed int to Speed int w and from Speed der to Speed der w. The
aim of the RPM window is to change the speed of regulation (reaction) in case the actual RPM differs
significantly from Requested RPM.
Speed int w [%]
Integration part of the PID regulation loop in case the actual RPM differs from Requested RPM for
more than RPM window.
Step: 1 %
Range: 0-100 %
Speed der w [%]
Derivative part of the PID regulation loop in case the actual RPM differs from Requested RPM for
more than RPM window.
Step: 0,1 %
Range: 0,0-100,0 %
Load gain [%]
Gain of the PID speed regulation loop.
Step: 0.1 %
Range: 0.0 – 200.0 %
Hint:
Setpoint is active for loaded engine.
Load int [%]
Integration of the PID speed regulation loop.
Step: 0.1 %
Range: 0.0 – 100.0 %
Hint:
Setpoint is active for loaded engine.
Load der [%]
Derivative part of the PID speed regulation loop.
Step: 0.1 %
Range: 0.0 – 100.0 %
Hint:
Setpoint is active for loaded engine.
Droop [%]
Droop of speed governor. The governor lovers the speed reference by Droop percent of the Nominal
RPM over the range from zero to MaxFuel.
Step: 0.1 %
Range: 0.0 – 100.0 %
