ECON-4 1.4.0 Global Guide
28
5.2 Entering password
5.2.1 Modify password from WinScope
WinScope PCprogram is used for modifying Setpoints.
Enter password
Password is a four-digit number. Password enables to change set points from WinScope PC program. Use icon
to activate a dialog box for password.
Change password
Use icon to activate a dialog box for password change. The password has to be entered to activated this
icon.
5.2.2 Modify password from GenConfig
Certain Setpoints can be modified directly from GenConfigPCtool. For information how to enter password in
GenConfig please see GenConfig Global Guide.
5.3 Data
Following data are communicated between IS-NT (specific sw branches only) and ECON-4 via CAN bus.
Correct function depends on configuration by PC GenConfig software.
5.3.1 Data Binary inputs
Following data from ECON-4 can be used for states indication or alarms activation.
ECON-4 Name Function
BI1 Bin1 Physical input state, reserve
BI2 Bin2 GCB Fdbck Physical input state
BI3 Bin3 Nominal Physical input state
BI4 Bin4 SpeedUp Physical input state
BI5 Bin5 SpeedDown Physical input state
BI6 Bin6 Run/Stop Physical input state
BI7 Bin7 Droop Physical input state
BI8 Bin8 Physical input state, reserve
BI9 Reserve
BI10 Reserve
BI11 Engine running ECON-4 state indication
BI12 OverSpeed Sd ECON-4 state indication
BI13 PID limit Fuel is on limit
