ComAp ECON-4 User Manual

ECON-4 1.4.0 Global Guide
69
8.1.6 Act type 1 – predefined for Woodward ITB 0-200 mA
There are 4 identical groups of setpoints in ECON-4. They are used to setup the output circuits for particular
types of actuators and tune the actuator position PID loop.
Note: Normally these Actuator type setpoints are predefined from the factory and there is no need to readjust
them. Modify them if you have a non-standard, or non listed actuator only – see List of tested actuators by
ComAp on page 74
Setpoint group ActType 1,2,3,4 Related FW 1.4.0
Range [units] 0.0 – 1000.0 [%]
Default value 50% Force value NO
Step 0.1 %
Comm object 11109 Related applications ALL
Setpoint visibility WinScope only
Description
Gain of the PID actuator position control loop.
Act gain
6 back to List of setpoints
Setpoint group ActType 1,2,3,4 Related FW 1.4.0
Range [units] 0 – 1000 [%]
Default value 20% Force value NO
Step 1 %
Comm object 11110 Related applications ALL
Setpoint visibility WinScope only
Description
Integration factor of the PID actuator position control loop.
Act int
6 back to List of setpoints
Setpoint group ActType 1,2,3,4 Related FW
1.4.0
configured ECON-4 extension
module
Range [units] 0 – 1000 %
Default value 0% Force value NO
Step 1 %
Comm object 11111 Related applications ALL
Setpoint visibility WinScope only
Description
Derivation factor of the PID actuator position control loop.
Act der
6 back to List of setpoints
