ComAp ECON-4

ECON-4 1.4.0 Global Guide
51
Setpoint group Engine RPM Related FW
1.4.0
configured ECON-4 extension
module
Range [units] 1 - 20 [%]
Default value 8 % Force value NO
Step 1 %
Comm object 7193 Related applications ALL
Setpoint visibility Always
Description
Percentage Change of Requested RPM from Nominal RPM. This setpoint defines the maximum allowable
change of requested RPM from the Nominal RPM value in case the BIN or ANA control of RPM is used.
Use this setpoint to enlarge maximum allowable swing of the required RPM. Setpoint is by default adjusted
to 8% which should fulfill the most of installations.
PerChSpdNom
6 back to List of setpoints
Setpoint group Main PID Related FW
1.4.0
configured ECON-4
ADVextension module
Range [units] IDLE FUEL – CLOSE
Default value - Force value NO
Step -
Comm object 14409 Related applications ALL
Setpoint visibility WinScope only
Description
Value set to output GAS Dose when RPM reaches value in setpoint PreOverSpeed.
PreOverSpReduct
6 back to List of setpoints
8.1.4 Group: Engine StartGroup: ECON4-EngStart
Setpoint group Engine RPM Related FW 1.4.0
Range [units] Start RPM - Nominal RPM
Default value 10% Force value NO
Step 1 %
Comm object 7172 Related applications ALL
Setpoint visibility Always
Description
Initial position of the actuator during start
InitStart dose
6 back to List of setpoints
