ComAp ECON-4 User Manual

ECON-4 1.4.0 Global Guide
72
Setting is active when Main PID: Actuator type = Act type 3. Setpoint structure see Act type 1 – predefined
for Woodward ITB 0-200 mA on page 69.
6 back to List of setpoints
8.1.9 Act type 4 – predefined for Heinzmann STG 10
There are 4 identical groups of setpoints in ECON-4. They are used to setup the output circuits for particular
types of actuators and tune the actuator position PID loop.
Note: Normally these Actuator type setpoints are predefined from the factory and there is no need to readjust
them. Modify them if you have a non-standard, or non listed actuator only – see List of tested actuators by
ComAp on page 74
Setting is active when Main PID: Actuator type = Act type 4. Setpoint structure see Act type 1 – predefined
for Woodward ITB 0-200 mA on page 69.
6 back to List of setpoints
8.1.10 Group: Analog sensors
Setpoint group Analog sensors Related FW
1.4.0
configured ECON-4 extension
module
Range [units] Range: 0.0 – 100.0 %
Default value 0.0 Force value NO
Step 0.1 %
Comm object 11125 Related applications ALL
Setpoint visibility WinScope only
Description
Value of analog input SPEED REQUEST for minimum possible speed reference (Nominal RPM-8%).
LoReqSpeed Inp
Note: It is active only if the setpoint Speed request = ANA.
6 back to List of setpoints
Setpoint group Analog sensors Related FW
1.4.0
configured ECON-4 extension
module
Range [units] 0.0 – 100.0 %
Default value 100 % Force value NO
Step 0.1 %
Comm object 11126 Related applications ALL
Setpoint visibility WinScope only
Description
Engine idle speed.
HiReqSpeed Inp
Note: Input SPEED REQUEST active only if the setpoint Speed request = ANA.
