ECON-4 1.4.0 Global Guide
44
8.1 Setpoints
What setpoints are:Setpoints are analog, binary or special data objects which are used for adjusting the
controller to the specific environment. Setpoints are organized into groups according to their meaning. Setpoints
can be adjusted from the controller front panel, PC, MODBUS, etc. All setpoints can be protected by a
password against unauthorized changes. Password protection can be assigned to the setpoints during the
configuration procedure.
See the chapter Entering password (page 28)for the instructions how to enter and modify a password.
IMPORTANT: Setpoints are organized in logical groups for better orientation. Use WinScope or
InteliMonitor software to modify the setpoints. For details see chapter ECON-4 configuration and
PC tools (page 32)
8.1.1 List of setpoint groups
8.1.3 Group: Engine StartGroup: ECON4-EngRPM 46
8.1.4 Group: Engine StartGroup: ECON4-EngStart 51
8.1.5 Group: Main PIDGroup: ECON-4-MainPID 53
8.1.6 Act type 1 – predefined for Woodward ITB 0-200 mA 69
8.1.7 Act type 2 – predefined for Woodward ITB PWM 71
8.1.8 Act type 3 –predefined for Woodward F-series PWM 71
8.1.9 Act type 4 – predefined for Heinzmann STG 10 72
8.1.10 Group: Analog sensors 72
8.1.11 List of tested actuators by ComAp 74
For full list of Setpoints go to the chapter List of setpoints (page 45).
