Accessory Modules for IL-NT, IC-NT, IA-NT and ID-Lite Global Guide
30
Current conversion table
20 mA/20.0 mA
Primary Converted
115 119
135 140
155 160
175 181
195 201
Voltage conversion table
100 mV/100.0 mV
Primary Converted
140 566
170 685
210 842
230 921
250 999
Current conversion table
20 mA/100.0
Primary Converted
116 60
135 70
155 80
174 90
194 100
Current conversion table
20 mA/60.0
Primary Converted
0 0
38 12
57 18
77 24
96 30
116 36
135 42
155 28
174 54
194 60
Current conversion table
4-20 mA/100.0
Primary Converted
38 0
54 10
77 25
100 40
116 50
139 65
155 75
178 90
194 100
Voltage conversion table
4-20 mV/60.0
Primary Converted
38 0
54 6
77 15
100 24
116 30
139 39
155 45
178 54
194 60
Note:
1. If other sensor not included from this list is configured, the unit returns sensor fail.
2. PC software tool configuration must correspond to jumpers setting.
3. Do not configure inputs 5 – 8 of analog inputs module in PC software tool - Analog inputs.
4. Do not configure outputs 2-8 of analog outputs module in PC software tool - Analog outputs.
Programming Firmware
Firmware upgrade is via AT-link (TTL). For programming is necessary to close jumper BOOT. RESET jumper
is used to reset the device. Close jumper to reset the device. For programming is used FlashProg PC tool.
4.5.5 LED indication
Binary inputs
Each binary input has LED which indicates input signal. LED is shining when input signal is set, and LED is
dark while input signal has other state.
Binary outputs
Binary output LED shining when binary output is set.
