Communication Guide, ©ComAp – March 2014 22
IGS-NT Communication Guide 03-2014.pdf
Ethernet connection (Direct)
The Internet (Ethernet) connection is a point-to-point connection between a PC and a controller or site
via an TCP/IP protocol-based network. The physical configuration of such network can be a small
local area ethernet network as well as the Internet.
Controllers
Available ports or modules
Available ports or modules
Hint:
Ethernet connection is available for all mentioned controllers via external bridge IG-IB or IB-NT (see
the chapter Ethernet connection via IG-IB/IB-NT).
Number of clients connected simultaneously
2 clients with InteliMonitor or WebSupervisor (Comap/TCP protocol)
2 clients with web interface
Using a web browser
Ethernet connection to controller makes possible using any web browser for basic monitoring and
adjustment of the controller. Simply put the IP address of the module into the address line in your web
browser like http://192.168.1.254 and then enter access code. In case of connection from web
browser there is 5 minutes timeout after closing the browser window. After that the client is
automatically logged out.
Ethernet connection settings
Parameters can be set via any type of connection (USB, RS232, Ethernet). Setup is provided via
InteliMonitor. For Ethernet connection set these parameters in Comms Settings group:
