ComAp Inteli Mains NTC BaseBox User Manual

Communication Guide, ©ComAp – March 2014 76
IGS-NT Communication Guide 03-2014.pdf
Cables for direct and modem connections
PC to RS232 on controller / I-LB
DB9 Female to DB9 Female
2
3
3
2
5
5
Modem to RS232 on controller / I-LB
Comms settings: MODEM (HW) or I-LB jumper HW control
DB9 Male to DB9 Female
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
Comms settings: MODEM (SW) or I-LB jumper SW control
DB9 Male to DB9 Female
2
2
3
3
5
5
USB cable
Use standard USB A-B cable (distance up to 5 meters).
CAUTION!
Use shielded USB cable only! (ComAp order code: USB-LINK CABLE 1.8m)
