Communication Guide, ©ComAp – March 2014 101
IGS-NT Communication Guide 03-2014.pdf
Ethernet converter from twisted pair (UTP/STP)
to optic
For galvanic separation
For cable length extension
Recommended equipment
Ethernet Media converters
o MOXA IMC-21A (http://www.moxa.com/product/IMC-21A.htm)
Multimode/single mode versions. One Ethernet port. Up to 40km (single mode). SC/ST
connectors.
Ethernet Switches
o MOXA EDS-305/308 series (http://www.moxa.com/product/eds-308305.htm)
Unmanaged switches. Multimode/single mode versions. 4/6 Ethernet RJ-45 ports, 1/2
optical ports. Up to 40km (single mode). Alarm contact. SC/ST connectors.
o MOXA EDS-405A/408A series (http://www.moxa.com/product/eds-408405a.htm)
Managed switches. Multimode/single mode versions. 4/6 Ethernet RJ-45 ports, 1/2/3
optical ports. Up to 40km (single mode). Redundant power supply. Alarm contact. SC/ST
connectors.
