InteliLite Global Guide
284
Setpoint group CM-4G-GPS Related FW 1.2.1
Range [units] 0,0..99,9 [km]
Default value 0,0 km Alternative config NO
Step 0,1 km
Comm object 11677 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Radius for circle area 1. When the gen-set leaves this area, Fence 1 Protection (page 286) is activated after
Fence 1 Delay (page 284).
Note: The center of this circle area is defined by "Home" position - setpoints Home Longitude (page 283)
and Home Latitude (page 283).
Fence Radius 1
6 back to List of setpoints
Setpoint group CM-4G-GPS Related FW 1.2.1
Range [units] 0,0..99,9 [km]
Default value 0,0 km Alternative config NO
Step 0,1 km
Comm object 14608 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Radius for circle area 2. When the gen-set leaves this area, Fence 2 Protection (page 287) is activated after
Fence 2 Delay (page 285).
Note: The center of this circle area is defined by "Home" position - setpoints Home Longitude (page 283)
and Home Latitude (page 283).
Fence Radius 2
6 back to List of setpoints
Setpoint group CM-4G-GPS Related FW 1.2.1
Range [units] 0..3600 [s]
Default value 0 s Alternative config NO
Step 1 s
Comm object 11682 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Delay for Fence 1 Protection (page 286).
Fence 1 Delay
6 back to List of setpoints
