InteliLite Global Guide
468
Related FW 1.2.1 Related applications AMF, MRS
Comm object 6
Description
Output closes when any sensor fail alarm appears.
The output opens, if:
No sensor fail alarm is active and
Fault reset button is pressed
AL Common Fls
6 back to Logical binary outputs alphabetically
Related FW 1.2.1 Related applications AMF, MRS
Comm object 4
Description
Output closes when any shutdown alarm appears.
The output opens, if:
No shutdown alarm is active and
Fault reset button is pressed
AL Common Sd
6 back to Logical binary outputs alphabetically
Related FW 1.2.1 Related applications AMF, MRS
Comm object 3
Description
Output closes when any warning alarm appears.
The output opens, if:
No warning alarm is active and
Fault reset button is pressed
AL Common Wrn
6 back to Logical binary outputs alphabetically
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1295
Description
The output is closed when there is the Wrn Coolant Temperature Low (page 567) alarm from the
COOLANT TEMP (PAGE 543) in the alarmlist or isn’t confirmed.
AL CoolantTemp Low
6 Logical binary outputs alphabetically (page 463)
