Comelit SIMPLEBUS2 - Operating Distance Specifications

SIMPLEBUS2 AUDIO-VIDEO
5
A MAX B MAX C MAX D MAX E MAX F MAX
G MAX
(see
page
8)
H MAX Art.1216
Comelit Art.4577/4579
1 mm²
(Ø 1.2 mm AWG 17)
200 m
(650 feet)
200 m
(650 feet)
200 m
(650 feet)
200 m
(650 feet)
150 m
(490 feet)
50 m
(165 feet)
50 m
(165 feet)
100 m
(330 feet)
2
1
UTP5 cat. 5 0.2 mm²
(Ø 0.5 mm AWG 24)
80 m
(260 feet)
150 m
(490 feet)
150 m
(490 feet)
150 m
(490 feet)
100 m
(330 feet)
60 m
(195 feet)
2
1
0.28 mm²
(Ø 0.6 mm AWG 23)
100 m
(330 feet)
150 m
(490 feet)
150 m
(490 feet)
150 m
(490 feet)
100 m
(330 feet)
5 m
(15 feet)
10 m
(30 feet)
60 m
(195 feet)
2
1
0.5 mm²
(Ø 0.8 mm AWG 20)
120 m
(395 feet)
100 m
(330 feet)
100 m
(330 feet)
100 m
(330 feet)
80 m
(260 feet)
25 m
(85 feet)
25 m
(82 feet)
60 m
(195 feet)
2
1
1 mm²
(Ø 1.2 mm AWG 17)
120 m
(395 feet)
150 m
(490 feet)
150 m
(490 feet)
150 m
(490 feet)
80 m
(260 feet)
50 m
(165 feet)
50 m
(165 feet)
60 m
(195 feet)
2
1
1 mm²
(Ø 1.2 mm AWG 17)

120 m
(395 feet)
80 m
(260 feet)
80 m
(260 feet)
80 m
(260 feet)
50 m
(165 feet)
50 m
(165 feet)
50 m
(165 feet)
40 m
(130 feet)
2
1
1.5 mm²
(Ø 1.4 mm AWG 15)
150 m
(490 feet)
100 m
(330 feet)
100 m
(330 feet)
100 m
(330 feet)
80 m
(260 feet)
75 m
(245 feet)
100 m
(330 feet)
60 m
(195 feet)
2
1
2.5 mm²
(Ø 1.8 mm AWG 13)
150 m
(490 feet)
100 m
(330 feet)
100 m
(330 feet)
100 m
(330 feet)
80 m
(260 feet)
100 m
(330 feet)
150 m
(490 feet)
60 m
(195 feet)
Operating distances
B
A
F
H
1214/2C
1595
1216
6741W
6741W/BM + 6710
3 DOOR ENTRY MONITORS / ART. 1229A MAX
4888C
UT1020
S3
DIP 1
Compatible secondary door entry monitors: 6701W (/BM), 6701W/8, 6721W (/BM), 6801W (/BM), 6601W (/BM)
