Example of maximum expansion per apartment
1214/2C
1214/2C
APARTMENT 6: max 4 internal units including 2 main internal units
Art. 6701W 6701W/8
Art. 6741W
Art. 6801W
Art. 6721W
Art. 6801W
Art. 6601W
Art. 6601W
1214/2C
1214/2C
APARTMENT 4: max 4 internal units including 2 main internal units
APARTMENT 3: max 4 internal units including 2 main internal units + 2 main internal units powered separately
APARTMENT 5: max 4 internal units including 2 main internal units
1214/2C
1214/2C
APARTMENT 2: max 3 internal units including 2 main internal units
APARTMENT 1: max 4 internal units including 2 main internal units + 2 main internal units powered separately
4888C
CV1
CV2
CV1
CV2
1214/2C
APARTMENT 7: max 4 internal units including 1 main internal unit
6741W 6721W 6721W 6721W
A single 6741W (/BM) door entry monitor can be installed for each user code; this will also be the only main door entry monitor.
