37
accidental escape of the pumped liquid.
• Do not deactivate or tamper with the controls and the safety devices and the pressure unloader/regulation
valve.
a) Unroll the delivery hose (1) completely.
b) Check that the lance (13) adjuster(24) is turned completely in the
“S”
direction so lever (26) can be moved
into the
“OFF”
position. If provided, move the tap lever(39) into the
“OFF”
position.
c) Reset delivery pressure as follows:
- motor pumps with MC8 and MC18: turn knob (29) completely anticlockwise;
- other motor pumps: put lever(30) into the
“BYPASS”
position.
d) Start the machine for priming to start. If the machine has an electric motor, turn the main switch on, putting
it into position “1” (bear in mind the warning concerning three-phase motors given in the
“CHECKING
AND CONNECTING UP TO THE POWER SUPPLY"
paragraph). In machines tted with a combustion engine,
follow the instructions for starting given in the engine manual.
e) Pressurise the machine in the following way:
- when installed, put lever(30) into the
“PRESS”
position;
- turn knob(29) until the pressure value wanted is reached (turning clockwise to increase pressure,
anticlockwise to reduce it); if installed, the pressure is shown on the pressure gauge(36).
f) If provided, move the tap lever(39) into the
“ON”
position.
g) Turn the lance (13) lever(26) to adjust the spraying angle (from an empty cone to a thin solid jet). The
position of the spray chosen can be xed with the adjuster (24). We advise doing this spraying the lance
inside the tank so as not to disperse the chemical product.
h) The ow of liquid sprayed depends on working pressure, on the nozzle (27) used (the machine comes
with a standard 1.5 mm Ø nozzle) and on the spraying angle set. The nozzle to use for the type of job to
be done can be found in the following table (note that the ow rate given is the maximum, that is, for a
thin and solid jet).
PRESSURE
[bar - psi]
Ø NOZZLE
[mm]
5 - 72,5 10 - 145 15 - 217,5 20 - 290 30 - 435 40 - 580
1,0 1,0 - 0,26 1,5 - 0,40 1,8 - 0,48 2,1 - 0,55 2,5 - 0,66 2,9 - 0,77
1,2 1,4 - 0,37 1,9 - 0,50 2,4 - 0,63 2,8 - 0,74 3,4 - 0,90 3,9 - 1,03
1,5 2,0 - 0,53 2,8 - 0,74 3,4 - 0,90 3,9 - 1,03 4,8 - 1,27 5,6 - 1,48
1,8 2,2 - 0,58 3,2 - 0,85 3,9 - 1,03 4,5 - 1,19 5,5 - 1,45 6,3 - 1,66
2,0 2,6 - 0,69 3,7 - 0,98 4,5 - 1,19 5,2 - 1,37 6,4 - 1,69 7,4 - 1,95
FLOW RATE
[l/min - USgpm]
CAUTION
• To permit fast machine priming, proceed as indicated at point c) every time the tank is emptied of uid.
• During the rst hours of operation, it is best to check the oil level and, if necessary, top up the level,
following the instructions in the
“PRELIMINARY ACTIVITIES”
paragraph.
• Do not operate the machine:
- if it is too noisy and/or water or oil is dripping from it: in this case have it checked by a
SKILLED TECHNICIAN
;
- when exposed directly to sunlight, with ambient temperature above 40°C.
STOP
WARNING
• Also comply with the safety instructions regarding stopping contained in the manual of any
combustion engine equipping the machine.
• Always make sure that, once stop operations have been performed, no part of the machine is moving
and no pipes contain liquid under pressure.
• Once the machine has cooled down, be careful:
EN
