4. Cabling GE 800
10 1.1/1209
4. Cabling
1. Connection Intercom Server
2. Connection Intercom Terminals
3. Connection Inputs /Outputs
4. Connection of multiple Intercom Servers
Connection Intercom Server
Installation Board G8A-GEN
Installation Board G8A-NET
G8A-GEN
1
2
3
4
5
6
7
8
9
+30V
24V AC
24V AC
S1WS1W
S2
S1
IN2
IN1
MU2
MU1
S2WS2W
S1S1
S2S2
Music /
alarm
input
Floating
contacts
Grounding point
for wrist strap
grounding
Programming socket
(parallel to G8-GEN)
Door opener
e.g.:
Power supply
Wiring outputs
Grounding
1....GND
(Shield)
2....TXD
3....RXD
4....NC
5....GND
6....NC
7....NC
8....NC
9....NC
Power supply GE 800
DC
or
AC
UPLINK
DOWNLINK
OUT (GEV)
IN (GEV)
Ethernet (configuration)
Connection to network cards (G8-CNET-W, G8-CNET-E1)
or GE 700 (G7-GEV)
