General Information GE 800
46 1.1/1209
General Information
Expansion
Line length Subscribers
Station Series EE 311A, EE 811A
Digital stations
Station Series EE 411
All data about line lengths (series EE 411 with and without display) correspond to a loudspeaker at-
tenuation of approx. 9 dB and a microphone attenuation of approx. 3 dB. 9 dB correspond to approx. 3
volume steps adjusted at an EE 411, 3 dB refer to approx. 1 volume step.
Stations with display (Station Series EE 411):
The maximum line capacity for cables not listed in this table is 90 nF. This capacity refers to: A against
B, C against D, C/D together against A as well as the single lines A, B, C, D against an eventual shield
(ground). This capacity can be measured with a multimeter. Measure with open end of the line: A
against B, C against D, C/D together against A, A against shield, B against shield, C against shield and
D against shield. All these capacity values may not be higher than 90 nF.
Stations without display / power supply stations, amplifiers:
Basic expansion: Max. expansion per housing: Max. expansion (120 housings)
Subscribers: 0 112 30,000
Outputs: 2 224 1000
Inputs: 2 224 1000
Maximum cable length at diameter:
(power supply from Intercom Server)
Cable type: Reference: Capacity 24 V AC 30 V DC 26 V DC
J-02YS(St)Y Ethernet cable (z.B. Kat. 5) 48 nF 1,500 m 1,500 m 1,500 m
F-YAY Telecommunication cable: ø 0,6 / 0,8 mm
>135 / >73
Ohm / km
1,500 m 1,400 m 800 m
The indicated line length is valid for standard stations without additional ext. loudspeaker. With these line lengths max. the volume level 9 & dis-
play backlight intensity 9 is possible (Voltage Monitoring).
Maximum cable length at diameter:
Cable type: Reference: Capacity 0.5 mm 0.6 mm 0.8 mm
F-YAY Installation cablePVC 100 nF * 2,000 m 2,000 m
J-02YS(St)Y Cat. 5 cable, foamed polyethylene 45 nF
1,500 m
3,000 m with ext.
supply
2,000 m
3,000 m with ext.
supply
3,000 m
3,000 m with ext.
supply
*...no data, because this diameter is not available for this cable type.
Maximum cable length at diameter:
Cable type: Reference: Capacity 0.5 mm 0.6 mm 0.8 mm
J-Y(ST)Y Installation cable PVC 120 nF * 750 m 750 m
F-YAY Installation cable PVC 100 nF * 900 m 900 m
KC 102/104 Installation cable PVC 65 nF 1,000 m * *
F-2YA2Y Buried cable polyethylene 55 nF * 1,500 m 1,500 m
J-02YS(St)Y Cat. 5 cable, foamed polyethylene 45 nF 1,000 m * *
*...no data, because this diameter is not available for this cable type.
